CZI MP130 Digital voice broadcasting system
MP130 Digital voice broadcasting system
The MP130 is the UAV’s Long Range Acoustic Device (LRAD).
With ultra-high sound pressure, the MP130 can clearly transmit speech to a distance with a maximum range of more than 1,000 meters.
MP130 DRONE LOUD SPEAKER
Engineered for DJI Matrice 300 RTK and M200 Series
Long-range Voice Broadcasting
The CZZN MP130 is a long-range loudspeaker for DJI drones.
Small and lightweight, this Digital Voice Broadcasting System has a maximum volume of over 120dB and can emit sound from as far as 1,000m.
Use DJI Skyport for seamless compatibility with the DI M300 RTK and M200 Series V2 and V1. The loudspeaker can be controlled via CZZN software or DJI Pilot software.
The MP130 can be used for a variety of applications, such as search and rescue, traffic management, and following major disasters and incidents.
KEY FEATURES
The MP130 has a range of key features which makes it an effective tool to convey public safety messages to large crowds or to open a communication channel with nearby individuals during critical, lifesaving emergency operations.
-
Long Transmission
The MP130 can be controlled from afar, with a maximum distance of 10km, depending on the type of drone deployed.
-
Loud And Clear
The max volume exceeds 130dB, the effective broadcast range is 300-500 metres, and the max broadcast range is around 1,000 metres.
-
Multiple Play Modes
Broadcast modes include text-to-speech, scanning QR code to transmit text, voice broadcast and audio file playback.
-
Delicate Design
Automatic synchronous pitching function follows the camera’s pan-tilt-zoom to achieve the best broadcast.
APPLICATIONS
Drone loudspeaker has a range of use cases.
Industry Uses For MP130 Loud Speaker
The MP130 is a versatile tool that can be used in a range of scenarios. These include:
- Forest Search and Rescue: The MP130 raised the sound over a long distance to guide people to safety. It is especially useful when used in conjunction with a visible light camera or thermal sensor.
- Emergency Warning: The MP130 can transmit real-time voice recordings to warn of imminent dangers or to relay crucial information following an incident.
- Traffic Collisions: Police can deploy the MP130 to achieve long-distance traffic command and rapid communication. Crucial information can be relayed to people at the scene, including sharing road-closure updates and diverting traffic.
- Other Examples: This loudspeaker can be used to deal with natural resources protection, urban management, and maritime law enforcement.
Adapted models
- DJI Matrice 210 V2 series
- DJI Matrice 300 RTK
Parameter information
| Model |
MP130S/MP130C |
| Size |
140*140*125mm(L*W*H) |
| Weight |
550±5g |
| Power |
25W |
| Maximum sound pressure |
130dB |
| Effective broadcast range |
500m |
| Directivity |
80°x50 ° (Horizontal x Vertical) |
| Working temperature |
-20℃~+40℃ |
| Load interface |
DJI SKYPORT/ CZI adapter ring |
| Communications link |
DJI UAV link +LTE network link |
| Pitch Angle |
0 ~90° (M200 V2 series) |
| Play mode |
Real-time propaganda |
| Audio file storage format |
mp3/wav/m4a/flac/aac |
| App support system |
Android 5.0 and above |
